At least 25% greater WLL than traditional Grade 8 products.
Proof Load tested at 2.5 times the WLL with certification for each batch manufactured.
Fatigue rated to 20,000 cycles at 1.5 times the WLL.
Tempering temperature minimum 400°C.
Magnaflux crack detection is performed 100% on each batch.
- Material: Quenched and Tempered Alloy Steel
- Marking: According to standard, Size, grade, manufacturer ID, traceability.
- Temperature range: -40ºC up to +200°C (without reduction in WLL).
- Finish: Blue painted.
- Standard: EN 1677-3
- Safety factor: 4:1
- Grade: 10
